| Phase |
Three Phase |
Accuracy Class |
0-6A |
| Supply Voltage |
57.7/100V, 220/380V, 380V/660V |
Display Type |
Digital Only |
| Place of Origin |
Zhejiang, China |
Model Number |
KPM73A |
| Brand Name |
Mivectorele |
Dimensions |
96×96mm |
| Operating Temperature |
-25°C ~ +70°C |
Name |
Energy measuring instrument electronic energy meter |
| Display |
LCD |
Communication |
RS485 Port / MODBUS Protocol |
| Function |
Power quality analysis |
Measure Parameters |
Full electric parameter analysis |
| Harmonic calculation |
2-51th |
Power Supply |
85~265V AC, 80-300VDC |
| Insulation Resistance |
>50MΩ |
Active energy accuracy |
0.5S |
| Altitude |
No more than 4000m |
|
|
