| Max. Voltage |
250V |
Max. Current |
5A |
| Switch Combination |
1NO1NC, 1NO, 2NO2NC, 2NO |
IP level |
IP65 |
| Head Type |
Round Head, Flat Head |
Mechanical Life |
1000000 Times |
| Terminal Type |
Pin Terminal, Screw Terminal, Plug Terminal |
Illuminated Type |
Ring Illuminated |
| LED |
Yes |
Application |
Industrial Control, Home Appliance, Electric |
| Whether The Smart |
No |
Structure |
Mechanical |
| Place of Origin |
Zhejiang, China |
Model Number |
GQ Seriese |
| Brand Name |
Mivectorele |
Mounting Hole Size |
12mm/16mm/19mm/22mm/25mm/30mm |
| Head type |
High round/ flat round/ High round /Custom |
Material |
Stainless Steel / Aluminium Alloy |
| Function |
1NO1NC/2NO2NC |
LED color |
Red.Yellow.Green.White.Blue.Orange. Double color. Tri-color |
| Operation type |
Momentary/Latching/Delayed |
Certification |
CE RoHS REACH CCC |
| Protection Level |
IP65/IP67 |
– |
– |
